型号Model | FMZ4D-09 | FMZ4D-12 | FMZ4D-15 | FMZ4D-18 |
Dim (W×D×H, mm) | 900×600×1800 | 1200×600×1800 | 1500×600×1800 | 1800×600×1800 |
Dim (W×D×H, in) | 35.4×23.6×70.9 | 47.2×23.6×70.9 | 59.1×23.6×70.9 | 70.9×23.6×70.9 |
Temp. (°C) | 4~10°C | 4~10°C | 4~10°C | 4~10°C |
Temp. (°F) | 39~50°F | 39~50°F | 39~50°F | 39~50°F |
Adjustable Shelves | 4 layers | 4 layers | 4 layers | 4 layers |
Power(W) | 1000 | 1500 | 2000 | 2300 |
Specifications subject to change without notice.
Design
- Icoldbox commercial refrigerated display case features high-efficiency large-capacity merchandising, superior cooling performance, and a stylish anti-fog glass front panel, elegantly showcasing high-end desserts and pastries.
Refrigeration System
- The factory - independently designed capillary system utilizes an eco - friendly R290 hydrocarbon refrigerant (with zero ODP and low GWP), significantly cutting down greenhouse gas emissions to contribute to achieving “carbon neutrality”.
- The mature and high-quality refrigeration system is equipped with a branded compressor, featuring high refrigeration efficiency and energy-saving emission reduction.
- Copper tube fin heat dissipation rapidly dissipates heat, keeping equipment at optimal working temperature to boost efficiency and enhance stability/reliability.
- The condensing unit is installed at the bottom, facilitating maintenance and cleaning, and items can be placed on the top.
- Adopting air-cooled refrigeration mode, it features fast cooling speed, precise temperature control, frost-free and maintenance-free design, good freshness preservation effect, and more flexible storage space.
Cabinet Construction
- The side panels are made of double-layer hollow tempered glass (stainless steel side panels can be customized).
- Other surfaces and the interior are made of high-quality stainless steel, which is corrosion-resistant, durable and easy to clean.
- Exterior options: natural stainless steel (authentic metallic look) or black titanium brushed stainless steel (sleek, premium finish). Both are durable and stylish, selectable by scenario and style.
- Insulation - The entire cabinet structure is foamed with high-density polyurethane insulation material, with the thickness increased by 20%. This material has zero Ozone Depletion Potential (ODP) and zero Global Warming Potential (GWP).
- High-quality stainless steel heavy-duty frame rails, equipped with multiple adjustable stainless steel shelves: durable, corrosion-resistant and freely adjustable.
- Air curtain cabinets are available in custom widths ranging from 900 to 1800, tailored to your specific needs.
Shelving
- Each zone is equipped with 3 height-adjustable heavy-duty stainless steel shelves. The material of the shelf support pillars is the same as that of the cabinet interior.
- The number of layers and the material of the shelves can be customized (optional: stainless steel wire shelves, glass shelves, perforated shelves).
Lighting
- Energy-saving lamps provide uniform illumination.
Model Features
- External digital temperature display with selectable Fahrenheit (°F)/Celsius (°C).
- Evaporator with optional epoxy resin coating for anti-corrosion and durability.
Electrical
- The equipment is factory pre-wired for direct connection to a single-phase 220V power supply with 10A/16A dedicated sockets. Includes power cord and plug kit.
- Standard triangular plug (connectors compliant with relevant standards of different countries are available).
Optional Features/accessories Upcharge And Lead Times May Apply.
- Energy-saving lamps provide uniform illumination.
- The side panels can be customized with stainless steel material
- Additional shelves (optional stainless steel wire shelves, glass shelves, perforated shelves)
- Variable frequency temperature sensor (optional)
- Evaporator with optional epoxy resin coating
- Supports and casters customizable as required
- Connectors customizable for European, British standards, etc.
- Shape, thickness, material, cooling method, and internal structure all customizable
